Small and medium pitch gear hobbing and shaping (module or pitch). Plus the support machinery to put it all together into transmissions and machinery of all kinds. Lathes for blanks, tools for deburring, heat treating ovens, NIST certified hand tools, gear inspection machines and software.

PFAUTER RS00 and RSOOS HOBBERS
Great for small to medium pitch production of : external spur, helical, ratchet, sprocket gears. Four machines for manufacturing flexibility.
(Pinion and Gear)
Helical(Left and Right)


  • WORKING RANGE (BEST)

  • Diametral pitch: 16 and finer

  • Up to 10" Outside Diameter
  • Specifications
  • Machine Index Constants: Elk 8, Jersey 16, Santa Fe 16, Olive 32, Aberdeen TBD
MIKRON 79 EP GEAR HOBBER
Great for hobbing instrument gears

  •

  • WORKING RANGE (FULL)

  • Max Diameter: 40 mm with 24mm hobs,

  •               46 mm with 18mm hobs

  • Maximum Module(Pitch): 1 Module (26DP)
    Minimum Tooth Count 6
  • Read more specifications
  •
MIKRON 132.02 GEAR HOBBER
Great for hobbing instrument gears and small motor gearshafts
Hydraulic Machine Operation
GLEASON 2A BEVEL GEAR MACHINE (CONIFLEX)
Great for small-to-medium production of bevel gears


  • WORKING RANGE (FULL)

  • Diametral pitch: 16 and finer
    Cone distance: up to 2.25"
    Face width: up to 0.43"
    Read more specifications

  • The Last Tooth
GEAR MEASUREMENT Roll Testers
Fellows Gear Center Distancing Tools
Gleason Bevel Gear Checkers
Vari-Roll GC-4
Parkson 9N Tester
Mahr Nr. 544
S & F

  • OVERALL WORKING RANGE

  • Minimum Diameter: 2mm

  • Max Diameter: 4 inches

  • Minimum Module(Pitch): 0.2 Module, (128DP)
  • Maximum Module(Pitch): 1.6 Module, (16DP)



                                    MicroGear



Tsugami TUG 300 Cylindrical Grinder
Cylindrical grinding for fixtures, bearing journals, precision fits
Manufactured in Tokyo 1952





  • WORKING RANGE Estimate

  • 5C workholding in spindle

  • Swing 8" Diameter
  • Between Centers estimate 14 inches
  • Main Wheel Swivel 10" wheel
  • Swivel Table
  •
  •
MIKRON 104.01 THREAD MILLING MACHINE
For thread milling worms and threads
This is a work in progress...

  •

  • WORKING RANGE (FULL)

  • Max Diameter: 2 3/8" inches

  • Maximum Module(Pitch): 64 TPI to 6 TP
  • Main Characteristics
  •
  •
MIKRON 121 HOB SHARPENER (Q2)
Great at grinding hobs to restore sharpness

  •

  • WORKING RANGE (FULL)

  • Diameter: 16 to 50mm, width up to 25mm

  • Number of flutes: 10, 12, 15, 20, 30

  • Read more specifications
  •
MIKRON A60 HOB SHARPENER
Great at grinding hobs to restore sharpness
CNC TSUGAMI M08J-II LATHE
Great for small-to-large quantity precision: turning, threading, and boring of anything circular (gear blanks, tubes, etc.) Bar-feeding makes quick work on high quantities and temperature compensation ensures all parts come out identical – first to last!

  •

  • WORKING RANGE (BEST)

  • Up to 2.5" diameter, 6" long; large quantities
  •
  • WORKING RANGE (FULL)
  • Up to 11" diameter, 11.4" long

  • Read more specifications
SCHAUBLIN 102N MANUAL LATHE
Great for small quantity precision turning and boring

  •

  • WORKING RANGE (FULL)

  • Up to 5/8" diameter, 4 inches long

OKUMA MANUAL LATHE
Great for small quantites of large pieces: turning, threading, boring,
especially for pipes, tubes, and long shafts
  •
  • WORKING RANGE (BEST)
  • 3/4" to 11" diameter, 72" long

  • WORKING RANGE (FULL)
  • Up to 11" diameter, 72" long

  • Thread Chart
  • Read more specifications
  •
CNC HAAS TM3-P MILL
Great for small-to-large quantity: milling, engraving, drilling, and cutting with complex geometries, curves, and 3D features

  •

  • WORKING RANGE (3-AXIS)

  • Up to 40" x 20" x 16"

  •
  • WORKING RANGE (4-AXIS)
  • Up to 3.5" diameter, 20 pounds
  • Read more specifications
MOORE JIG BORER
Great for small quantity precision drilling and boring

  •

  • WORKING RANGE (BEST)

  • Up to 16" long, 10" wide, 12" tall

  •
  • WORKING RANGE (FULL)
  • Up to 19" long, 11" wide, 20" tall

  • Read more specifications
SIXIS MANUAL MILL
Great for small quantity milling and drilling

  •

  • WORKING RANGE (FULL)

  • Up to 6" x 4" x 3"

  • Read more about Sixis
HOT SHOT 1200 HEAT-TREAT OVEN
Great for: single item and batch process heat treating: hardening, quenching, annealing, tempering

  •

  • WORKING RANGE (FULL)

  • Up to 10" x 10" x 12", 2000ºF

  • Read more specifications
MAKERBOT REPLICATOR 2 3D PRINTER
Great for small quantity prototypes, proofs-of-concept and quick testing
  •
  • WORKING RANGE (FULL)
  • Up to 11.2" x 6" x 6.1"
  •
  • Read more specifications
